    ECOSYS MA2600cwfx

    The ECOSYS MA2600cwfx is a compact and reliable 4-in-1 colour multifunctional for professional use. Engineered to offer maximum productivity to small and medium workgroups

    • Enterprise level information security to protect against threats
    • Exceptional low operating cost thanks to Long life parts and high capacity toner.
    • Integration of personal cloud storage services
    • Print speed up to 26 ppm b&w and 26 ppm colour
    • Optional additional paper feeder for a total of 550 sheets
    • Built in wireless network
    Engine speed
    Engine speed

    Up to 26 pages A4 per minute in colour and b/w

    Resolution
    Resolution

    1,200 x 1,200 dpi print at reduced speed, multibit technology for print quality of up to 9,600 x 600 dpi (print), 600 x 600 dpi, 256 greyscales per colour (scan/copy)

    Weight
    Weight

    Approx. 26 kg including toner container

    Dimensions (W x D x H)
    Dimensions (W x D x H)

    410 x 416 x 457 mm

    ECOSYS makes your office more sustainable and efficient

    Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.

    • ECOSYS MA2600cwfx drivers
    • ECOSYS MA2600cwfx documentation
    • ECOSYS MA2600cwfx software

    Main Specifications

    General
    • General
    • Paper handling
    • Print
    • Copy
    • Scan
    • Fax
    540x540-MFP_MA2600cwfx_comb01_left_01-removebg
    General type
    Colour multifunctional for A4 format
    Engine speed
    Up to 26 pages A4 per minute in colour and b/w
    Warm-up time
    Approx. 29 seconds or less
    Power consumption
    Copy / Print (b/w / colour): 375 W, Ready mode: 41 W, Sleep-mode: 0.4W
    Warranty
    1-year warranty as standard (depending on the country). KYOCERA guarantees the drum and developer for 3 years or maximum 100,000 pages (whichever occurs sooner), provided the printer is used and cleaned in accordance with the service instructions.
    Input capacity
    50-sheet multi-purpose tray; 60–220 g/m²; A4, A5, A6, B5, B6, Letter, Legal, Custom (70 x 148 mm–216 x 356 mm) 250-sheet universal cassette; 60–163 g/m²; A4, A5, A6, B5, B6, Letter, Legal, Custom (105 x 148–216 x 356 mm)
    Max. input capacity with options
    550 sheets
    Duplex unit
    Duplex as standard: Double-sided printing: 60 – 120 g/m²; A4, A5, B5, Letter, Legal
    Max. output capacity
    150 sheets face-down with paper full detection
    Document processor
    Dual scan document processor: 50-sheet, 60–90 g/m², A4, A5, A6, B5, Letter, Legal, Custom (105 x 148 to 216 x 356 mm)
    Processor
    ARM Cortex-A53 single core 1.0GHz
    Fonts
    93 scalable fonts for PCL/PostScript, 8 fonts for Windows Vista, 1 bitmap font, 45 barcodes (e.g. EAN8, EAN13, EAN128) with automatic generation of checksums as well as support of two-dimensional barcodes PDF-417 under PRESCRIBE (PCL and other barcodes available as an option)
    Applicable OS
    All current Windows operating systems, MAC OS X Version 10.8 or higher, Unix, Linux as well as other operating systems on request
    Max. original size
    A4/legal
    Continuous copy
    1 - 999
    Zoom range
    25 - 400 % in 1% steps
    Preset magnification ratios
    7 Reductions/5 Enlargements
    Image adjustments
    Text + Photo, Photo, Text, Map, Printed document
    Digital copy features
    Auto Colour Mode, Scan-once-copy-many, electronic sort, 2in1, 4in1, ID-card copy, priority print, program, auto duplex copy, continuous scan, auto cassette change, copy density control
    Scan functionalities
    Scan-to-e-mail (SMTP), Scan-to-FTP (FTP over SSL), Scan-to-SMB, Scan to USB Host, TWAIN scan (USB, network), WSD (WIA) scan (USB, network)
    Scan speed
    54 ipm (300 dpi, A4, b/w, duplex), 44 ipm (300 dpi, A4, colour, duplex)
    Scan features
    Integrated address book, Active directory support, encrypted data transfer, Blank sheet skip
    Scan resolution
    600, 400, 300, 200 dpi (256 grey scales per colour)
    Max. scan size
    Max. A4
    File type
    TIFF, PDF, PDF/A , high compression PDF, encrypted PDF, JPEG, XPS
    Original recognition
    Text + Photo, Photo, Text, Light Text, Text (for OCR)
    Compatibility
    ITU-T Super G3
    Modem speed
    Maks. 33,6 kbps
    Scanning speed
    2 seconds /sheet or less
    Transmission speed
    3 seconds or less
    Scanning density
    Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi
    Max. original size
    A4/legal
    Fax features
    Network fax, duplex transmission and reception,polling transmission and reception

    Options and Consumables

    Paper handling Options
    • Paper handling Options
    • Consumables
    • Options

    TK-5450C
    Average continuous toner yield in accordance with ISO/IEC 19798: Cyan toner for 3,200 pages A4. Starter toner yield: 1,500 pages A4.

    TK-5450K
    Average continuous toner yield in accordance with ISO/IEC 19798: Black toner for 4,100 pages A4. Starter toner yield: 1,500 pages A4.

    TK-5450M
    Average continuous magenta toner yield 3,200 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous magenta toner yield 1,500 pages in accordance with ISO /IEC 19798.

    TK-5450Y
    Average continuous yellow toner yield 3,200 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous yellow toner yield 1,500 pages in accordance with ISO /IEC 19798.

    KYOmulticode SD 3
    Contains all the functionalities of PCL Barcode Flash plus Unicode font “Andale Mono World Type“ which allows the user to print Asian fonts (Japanese, Korean, current and traditional Chinese)

    PCL Barcode SD
    Adds additional one- and two-dimensional barcodes to the KYOCERA device (as well as the resident and machine-readable fonts OCR-A, OCR-B)

    UG-33
    ThinPrint support

    UG-51/UPGRADE KIT
    Trusted Platform Module (TPM)

    USB IC Card Reader + Card Authentication Kit (B)
    Support for various authentication keys available
