TASKalfa 7054ci

The TASKalfa 7054ci is a real workhorse. Perfect, stable, quality images every time and enjoy sharp black text and high, impactful colour output thanks to the newly developed toner. This MFP is equipped with the latest security and highly productive intelligent features.

Up to 70/35 pages A4/A3 per minute in b/w and colour
Outstanding image quality due to advanced toner technology
High-level build in security features ensure optimum protection
Intelligent technology boosting overall performance with Super resolution and handwriting enhancement
Flexible paper handling from A6 up to SRA3 for up to 7,150 sheets

Smarter Working Made Simple: Download the e-book Smarter Working Made Simple: Download the e-book

Engine speed

Up to 70 pages A4 per minute. Up to 35 pages A3 per minute. Duplex print speed: 70 page per minute, A4. Duplex copy speed: 70 page per minute, A4.

Resolution

Print: 1,200 x 1,200 dpi, 4800 dpi equivalent x 1200 dpi, Copy/scan: 600 x 600 dpi

Time to first print

Approx. 3.7 / 5.0 seconds or less in b/w / colour

Turn your pains into gains

The TASKalfa 7054ci series will help you turn challenges into opportunities for smarter working.

Elevate your workplace with the TASKalfa 7054ci series!

Main specifications

General

General
Paper Handling
Print
Copy
Scan
Fax

General type

Colour multifunctional for A3 format

Engine speed

Up to 70 pages A4 per minute. Up to 35 pages A3 per minute. Duplex print speed: 70 page per minute, A4. Duplex copy speed: 70 page per minute, A4.

Warm-up time

Approx. 26 seconds or less

Power consumption

Printing: 1140 W, Copying: 1140 W, Ready mode: 45 W, Sleep-mode: 0.5 W

Input capacity

Multi-purpose tray: 150 sheets 52 - 300g/m2, (Banner 136–163 g/m2 ) A6R - SRA3 (320 x 450 mm), Custom (98 x 148 to 320 x 1,220 mm), Banner max. 304.8 x 1,220 mm Standard universal paper cassette: 2 x 500 sheet 52 - 300g/m2 Upper cassette A6R up to A4R, lower cassette A6R up to SRA3

Max. input capacity with options

7,150 sheets A4

Duplex unit

Standard 64 to 256 g/m2 SRA3 to A6R

Max. output capacity

Standard 500 sheets face-down, Max. 4300 sheets

Document processor

Optional

Processor

ARM A53 (Quad Core) 1.6GHz

Fonts

93 outline fonts (PCL), 136 fonts (KPDL 3), 8 fonts( Windows Vista), 1 Bitmap font 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)

Features

Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality, Super Resolution

Applicable OS

All current Windows operating systems, MAC OS X Version 10.9 or higher Unix, Linux as well as other operating systems on request

Max. original size

A3, Ledger

Continuous copy

1-9999

Zoom range

25 - 400 % in 1% steps

Preset magnification ratios

5 Reductions/5 Enlargements

Image adjustments

Text + Photo, Photo, Text, Diagram/Map

Digital copy features

Scan-once-copy-many, electronic sort, 2in1, 4in1, image repeat, page numbering, cover mode, booklet copy, interrupt copy, form overlay, margin shift, auto cassette change, skip blank page, ID copy

Scan functionalities

Scan to e-mail, Scan to FTP, Scan to SMB, Scan to USB Host, Scan to box, Network TWAIN, WIA/WSD scan

Scan speed

274 ipm (300 dpi, A4, duplex, b/w, with DP-7160/7170), 274 ipm (300 dpi, A4, duplex. colour, with DP-7160/7170)

Scan resolution

600dpi x 600dpi , 400dpi x 400dpi , 200dpi x 400dpi, 300dpi x 300dpi , 200dpi x 200dpi , 200dpi x 100dpi 256 greyscales per colour

Max. scan size

A3, Ledger

File type

TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, Searchable PDF (Option), MS Office file (Option)

Original recognition

Text, photo, text + photo, Light Text / Fine Line, optimised for OCR

Compatibility

ITU-T Super G3

Modem speed

Max. 33.6 kbps

Scanning speed

2.0 seconds or less

Transmission speed

Max. 3 seconds (JBIG)

Scanning density

Normal: 200 x 100 dpi, fine: 200 x 200 dpi, superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, halftone: 256 greyscales

Max. original size

A3, Ledger, Banner: 1600mm

Fax features

Network faxing, rotate transmission, rotate reception, encrypted transmission and reception, duplex fax reception, memory reception, mailbox, remote diagnostics, polling transmission and reception, broadcast, Optional Internet-fax, dual fax with second fax system 12

Options and consumables

Paper Handling Options

Paper Handling Options
Consumables
Options

SH-10
Staple cartridge 3 x 5,000

SH-12
Staple cartridge 3 x 5,000

SH-14
Staple cartridge 5 x 5,000

TK-8555C
Toner cyan for 24,000 pages. Average continuous toner yield in accordance with 5 % A4 coverage.

TK-8555K
Toner black for 40,000 pages. Average continuous toner yield in accordance with 5 % A4 coverage.

TK-8555M
Toner magenta for 24,000 pages. Average continuous toner yield in accordance with 5 % A4 coverage.

TK-8555Y
Toner yellow for 24,000 pages. Average continuous toner yield in accordance with 5 % A4 coverage.

WT-8500
70,000 sheets or more (in accordance with ISO/IEC 19752)

CB-7200W
Wooden cabinet

CB-7210M
Metal cabinet

Card Authentication Kit (B)
Support for various authentication keys available

DT-730(B)
Document tray

Fax System 12
Super G3 Fax, network fax

HD-15
320 GB HDD hard disc for easy document management

HD-16
1TB HDD hard disc for easy document management

IB-37
Wireless Network Interface (USB: 5GHz/2.4GHz)

IB-38
Wireless Network Interface (USB: 2.4GHz)

IB-50
Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT

IB-51
Wireless LAN Interface (802.11b/g/n)

Internet Fax Kit
Type A

KPC-12
Paper clamp to protect paper for standard cassettes, PF-7150/PF-7120

KPC-13
Paper clamp to protect for PF-7140

KYOmulticode SD 3
Contains all the functionalities of PCL Barcode Flash plus Unicode font “Andale Mono World Type“ which allows the user to print Asian fonts (Japanese, Korean, current and traditional Chinese)

Keyboard Holder 10
For optional USB keyboard

NK-7120
Numeric keypad

PCL Barcode SD
Adds additional one- and two-dimensional barcodes to the KYOCERA device (as well as the resident and machine-readable fonts OCR-A, OCR-B)

Platen Cover
Type E

Printing System 17
Fiery® Controller

Scan extension Kit (A) AC
Scan to searchable PDF (embedded OCR)

UG-33
ThinPrint support

UG-34
Emulation (IBM Proprinter/EPSON LQ-850/Diablo 630)

USB IC Card Reader + Card Authentication Kit (B)
Support for various authentication keys available
